FEC-18-RM

Base Product: FEC

Fiber Optic Entrance Cabinet, 18 Drawers, Rack mounted

Find a Partner

Specifications

Finish making your selections or clear them to view relevant specifications.

Download

Features and Benefits

Provides splicing, administration and storage for outside plant (OSP) and intrafacility cables (IFC)
Offers a cost-effective, space-saving alternative to splicing on the fiber frame
Cabinets are designed for deployment in a building equipment area
Bend radius protection and discrete subunit routing paths ensure easy installation
Can deploy high count of stranded or ribbon fiber cables
Ultra high density splice capacity dependent on splice tray used

Specifications

Product Classification

Access	Front \| Rear
Cable Entry Location	Bottom \| Side \| Top
Cable Exit Location	Bottom \| Side \| Top
Color	Putty white
Mounting	Rack, EIA 23 in
Splice Drawers, quantity	18
Splice Trays Included, quantity	0
Splicing Capacity Note	18 times number of splices per tray (example 18x288 = 5184)

Environmental Space

Indoor

Included

Grommets

Agency	Classification
ROHS	Compliant/Exempted
CHINA-ROHS	Above maximum concentration value
REACH-SVHC	Compliant as per SVHC revision on www.commscope.com/ProductCompliance
UK-ROHS	Compliant/Exempted
